| Water Supply Watersheds Boundaries |
Watersheds in western Mecklenburg County, NC that are protected due to being adjacent to Charlotte Water's drinking water source, the Catawba River. These boundaries also indicate that special development restrictions apply within these areas. |
Link |
Mecklenburg County Open Mapping |
| Watershed Boundaries |
This dataset indicates the boundaries of watersheds Mecklenburg County, NC, which identify the creeks and streams that stormwater will flow into after a precipitation event. |
Link |
Mecklenburg County Open Mapping |
| Water Quality Buffers |
The dataset contains polygons representing riparian buffers along stream banks in Mecklenburg County, NC as well as indicating some piped streams where buffers are not required. The buffer types are determined by different ordinances and statues required at the local, state and Federal levels. Buffer types include: Post Construction Buffers; Surface Water Infrastructure Management (SWIM) buffers; Water Supply Watershed Buffers (WSW); and Wildlife Buffers. |
Link |
Mecklenburg County Open Mapping |
| Post Construction Districts |
Plan review ensures that sufficient post-construction structural controls will be implemented to protect water quality and mitigate the impacts of development on stream flows after construction is complete. The Water Quality Buffers dataset includes construction buffers identified for each creek or stream. |
Link |
Mecklenburg County Open Mapping |
| Wetlands |
This data represents the potential wetlands located within Mecklenburg County, North Carolina. A wetland is a land area that is saturated with water, either permanently or seasonally, that supports vegetation of aquatic plants adapted to the unique hydric soil. |
Link |
Mecklenburg County Open Mapping |
| Creeks and Streams |
Creeks and streams in Mecklenburg County. |
Link |
Mecklenburg County Open Mapping |
| Lakes and Ponds |
The dataset displays waterbodies along the Catawba River Basin from Lake Hickory thru Lake Norman, Mountain Island Lake, and Lake Wylie to Fishing Creek Lake at Great Falls, SC. This dataset also includes Pond water features within Mecklenburg County, NC. The dataset was created to provide users a coverage for display of the Catawba River as a shaded polygon on maps. |
Link |
Mecklenburg County Open Mapping |
| FEMA Floodplain |
A layer depicting the horizontal extent of the 1% annual chance flood event in Mecklenburg County, NC, based upon existing land use conditions. This floodplain serves as a basis of regulatory and planning activities at the local level and is utilized by the National Flood Insurance Program to determine insurance rates for affected properties. |
Link |
Mecklenburg County Open Mapping |
| Community Floodplain |
A layer depicting the horizontal extent of the 1% annual chance flood event in Mecklenburg County, NC, based upon future land use conditions. This floodplain serves as a basis of regulatory and planning activities at the local level. |
Link |
Mecklenburg County Open Mapping |
| FEMA Floodway |
Dataset contains polygons that represent the FEMA Floodway, an area that must be reserved in order to discharge of the 100-year flood without cumulatively increasing the water surface elevation more than 0.1 feet. No fill or construction is permitted in this area. |
Link |
Mecklenburg County Open Mapping |
| Community Encroachment Area |
An area of the floodplain that must be kept clear of any obstruction (fill dirt, buildings, etc.) as to not impede the flow of water. Development in this area is very restrictive, and usually requires a detailed engineering analysis (and local approval) prior to beginning development. |
Link |
Mecklenburg County Open Mapping |
| Cross Sections |
A line on a floodplain map indicating the discharges and water surface elevations that have been calculated for that section of the stream and floodplain. |
Link |
Mecklenburg County Open Mapping |
| Floodplain Models |
Floodplain model hydrologic and hydraulic (H&H) output file sets and GIS input files for Effective, Preliminary and Draft floodplain determinations in Mecklenburg County, NC, produced in accordance with FEMA Flood Insurance Studies (FIS) guidelines and specifications. Model filesets are packaged for immediate download and can be used with Hydrologic Engineering Center (HEC) software, such as the River Analysis System (HEC-RAS), Hydrologic Modeling System (HEC-HMS) and HEC-1. |
See Directory |
Mecklenburg County Exavault Cloud FTP |
| Floodplain Mapping |
Filesets from Effective, Preliminary and Draft floodplain determinations for Mecklenburg County, NC, produced in accordance with guidelines and specifications for FEMA Flood Insurance Studies (FIS). File types such as PDFs of FIRM maps, FIS reports and LOMR documents as well as a multitude of GIS and CAD files related to Regulatory and non-Regulatory floodplain mapping are available for immediate download. |
See Directory |
Mecklenburg County Exavault Cloud FTP |
| Storm Water Easements |
An easement is a right of use by one party over the property of another party, sometimes for a specific purpose. For Storm Water, easements are property interests which document the conditions under which Storm Water has permission to enter an easement area on private property to repair drainage issues and/or perform on-going maintenance. A storm drainage easement is a recorded, legal document which describes easement boundaries and any conditions and restrictions related to the permission granted by the property. |
See Dataset |
City of Charlotte Open Data Portal |
| Storm Water Inventory Pipes |
Storm Water inventoried pipes in Mecklenburg County, NC. |
See Dataset |
City of Charlotte Open Data Portal |
| Storm Water Inventory Structures |
Inventoried structures in Mecklenburg County. |
See Dataset |
City of Charlotte Open Data Portal |
| Storm Water Assumed Connectivity |
This service is for Storm Water assumed connectivity features to connect existing inventory. |
See Dataset |
City of Charlotte Open Data Portal |
| Storm Water Inventory Open Drainage |
Storm Water inventoried channels in Mecklenburg County. |
See Dataset |
City of Charlotte Open Data Portal |
| Protected Watershed Overlay |
This is a planning feature and used for regulatory purposes. Stormwater and creeks flow directly into lakes that supply drinking water; by state law, those watersheds are under additional zoning and development regulations. |
See Dataset |
City of Charlotte Open Data Portal |
